Gerber 97-022 and 97-014 Replacement Cartridge Kit
4-piece pressure balance kit for Gerber Safetemp 49-400 and 49-700 single-lever tub and shower valves.
Replaces these part numbers
| OEM part numbers | Aftermarket equivalents |
|---|---|
| Gerber 97-022 (G0097022) stem and bonnet Gerber 97-014 (G0097014) pressure balance spool Gerber 92-294 temperature limit stop Gerber 92-257 body O-ring | Everbilt 43284 Kissler 46-7214 Jerich 97501 HD Supply P313765 Grainger 45K890 |
Will it fit?
Fits
- Gerber Safetemp 49-400 series valves
- Gerber Safetemp 49-700 series valves, including 49-730, 49-731 and 49-733
- Gerber 49-830 valve (stem and bonnet only)
- 97-020 loop handle and 97-021 lever handle trim
Not compatible with
- Safetemp II GS-103 or GS-105 valves (95-154 or 95-152)
- Hardwater valves (92-298)
- 49-300 series valves with the 97-510 ceramic disc cartridge
- The 97-013 blue style assembly
- Treysta valves
Is this your part?
The original parts come out in pieces: a ribbed white bonnet with a brass stem on top, a white pressure balance spool below it, and a small splined limit stop dial on the stem. If yours came apart that way and the stack measures about 4.75 in. from stem tip to spool base, this is the kit. If the old cartridge pulled out as one solid ceramic disc unit, you have a different Gerber series.
When to replace it
The shower drips at the head or tub spout, water weeps around the handle, the temperature creeps hotter mid-shower, or it surges hot when a toilet flushes elsewhere in the house.
Specifications
| FourHome part | 4H2608775 |
|---|---|
| UPC | 850054895707 |
| Overall length | 4.75 in. (121 mm) |
| Body height | 3.75 in. (97 mm) |
| Body diameter | 1.77 in. (44 mm) |
| Materials | Engineered polymer body, brass stem, stainless steel spool internals, EPDM seals |
| Color | White |
What is in the box
- Stem and bonnet with brass rectangular broach stem
- Pressure balance spool
- Temperature limit stop
- Body O-ring, pre-installed
How to install it
Time: About 30 minutes. Tools: Hex key, Channel lock pliers, Silicone plumber's grease.
- Shut off the water and open the handle to bleed pressure.
- Remove the handle and escutcheon.
- Unscrew the bonnet nut counterclockwise.
- Pull the old stem and bonnet, then the spool below it.
- Grease the O-rings.
- Seat the new spool first, then the stem and bonnet, and thread the bonnet nut in hand-tight.
- Set the 92-294 limit stop to your maximum hot before turning the water back on, or the handle can travel to full hot.
Questions
Will this fit a Safetemp II valve?
No. Safetemp II GS-103 and GS-105 valves use the 95-154 or 95-152 cartridge. This kit is for the original Safetemp 49-400 and 49-700 series.
Do I need to buy the spool separately?
No. The spool, stem and bonnet, limit stop and body O-ring are all in the box.
Why is my shower too hot after the repair?
The limit stop was not set. Remove the handle, set the 92-294 stop to your maximum hot, and reinstall.
How do I find my valve series?
The series number is stamped on the valve body. Check it before ordering.
